Mô tả sản phẩm
- X-Axis pided into 2 axes and facing arrangement design realize 26% less floor space
- It solved negative effects of long stroke like thermal displacement and rigidity problem
- X-Axis accel/decel and rapid speed is increased doubled and it realized short cycle time
*SPECIFICATIONS:
| ITEMS | Unit | MTV-SX460 | |
|---|---|---|---|
| Slide Travel | X-Axis Travel | mm | 1,040 (520 + 520) |
| Y-Axis Travel | mm | 520 | |
| Z-Axis Travel | mm | 350 | |
| Height of Spindle Nose from Table | mm | 250 ~ 600 | |
| Table | Table Size | mm | 1,100 × 520 |
| Max. Load Capacity | kg | 400 | |
| Spindle | Max. Spindle Speed | min⁻¹ | 10,000 |
| Max. Speed Rigid Tapping | min⁻¹ | 5,000 | |
| Spindle Motor | kW | 15 / 11 / 7.5 / 5.5 | |
| Feed Rate | Rapid Traverse Rate (X, Y, Z Axis) | m/min | 100 (50 + 50), 50, 50 |
| Tool Turret / ATC | Shank of Tool Holders | — | BT40 + P40T-II |
| Tool Change System | — | Magazine direct system | |
| Tool Storage Capacity | tools | 12 (Option: 15) | |
| Max. Tool Diameter × Max. Tool Length | mm | φ80 × 250 | |
| Max. Tool Weight | kg | 4.0 | |
| Tool Change Time (T to T / C to C) | sec | 1.2 / 2.5 | |
| Size of Machine | Max. Height | mm | 2,595 |
| Height in Transportation | mm | 2,245 | |
| Required Floor Space (Width × Depth) | mm | 1,900 × 2,345 | |
| Machine Weight | kg | 3,900 | |
| NC Unit | CNC Controller | — | FANUC 0i-MF Plus |
| Power | Power Supply | V | AC200 / 220, 3 Phase |
| Accuracy | Positioning / Repeated Positioning Accuracy | mm | 0.010 / < 0.004 |
