Mô tả sản phẩm
SPECIFICATIONS:
| Item / Model | MV12BxⅡ | Mv16BxⅡ | ||
|---|---|---|---|---|
| Table (1.6m） | Table (3.0m） | Table (2.2m） | ||
| Axis travel | X-axis(mm) | 1,600 | 3,000 | 2,200 |
| Y-axis(mm) | 1,300 | 1,700 | ||
| Z-axis(mm) | 660 | |||
| Max. workpiece size between machine columns | Distance from spindle end to table surface(mm) | 200 ～ 860 | ||
| Throat clearance between columns(mm) | 1,460 | 2,000 | ||
| Spindle specification | Spindle taper | BT50 | ||
| Spindle speed(min-1) | 35 ～ 7,000 (Opt. 35～10,000） | |||
| Driving system | Built-in motor | |||
| Continuous rating (torque) (kW(Nm)) | 26 (305) | |||
| Short time rating (torque) (kW(Nm)) | 30 (382) | |||
| Lubricant type | Grease | |||
| Rapid traverse speed | X / Y / Z (m / min) | 48 / 32 / 32 | 32 / 32 / 32 | |
| Table specification | Table width × Table length(mm) | 1,300×1,600 | 1,300×3,000 | 1,800×2,200 |
| Loading Capacity(kg) | 3,000 | 5,000 | 8,000 | |
| Magazine | Max. tool weight(kg) | 20 | ||
| Max. tool length(mm) | 400 | |||
| Max. tool dia.(without an adjacent tool)(mm) | 125 (229) | |||
| Tool storage capacity (pcs) | 30 | |||
| Coolant guards | Specification | All around guard without ceiling | ||
| Floor space | Length in X axis direction (with keeping maintenance space)(mm) | 5,800 (6,300） | 8,640 (9,440） | 7,500 (8,000） |
| Length in Y axis direction (with keeping maintenance space)(mm) | 3,460 (4,090） | 3,460 (4,090） | 4,020 (4,650） | |
| Machine height(mm) | 3,460 | 3,560 | 3,460 | |
