Mô tả sản phẩm
- Spindle speed 4,000/min Maximum torque 2,793 Nm (285 kgf-1) High power machine with maximum output 45 kW.
- The spindle is driven by a two-speed helical gear.
- High precision cross-rail positioning made possible by 0.001mm increment NC command
- A powerful 400mm square ram enables powerful cutting.
- Heavy duty φ130mm main spindle is supported by double row cylindrical roller bearings
- It adopts oil mist lubrication for the bearings. In addition, the cooling oil is circulated around the bearing housing.
- Uses tool lock with self-lock
- #50 Spindle taper / Flange dual contact system (BIG plus) as standard. It improves surface finish quality and enables heavy duty milling with a long tool.
| Item/Model | MVR28/34DX | MVR33/39DX | MVR38/44DX | MVR43/49DX | ||
| Table | Working area | Width (mm) | 2000 | 2500 | 3000 | 3500 |
| Length (mm) | 4000 (Opt: 5000, 6000, 8000) | 5000 (Opt: 6000, 8000) | ||||
| Loading capacity (ton/m) | 25/4.0 (Opt: 30/5.0, 36/6.0, 48/8.0) | 35/5.0 (Opt: 42/6.0, 56/8.0) | ||||
| Throat clearance between columns (mm) | 2800 | 3300 | 3800 | 4300 | ||
| Distance from spindle end to table surface (mm) | 2050 | 3050 | 3050 | |||
| (Opt: 2550, 3050) | (Opt: 2050, 2550) | (Opt: 3550, 4050) | ||||
| (Opt: 3550, 4050) | (Opt: 3550, 4050) | - | ||||
| Ram | Ram size (mm) | 400x400 | ||||
| Spindle speed (rpm) | 7 to 4000 | |||||
| Spindle motor output (cont/30 min) (kW) | 37/45 (Opt: 45/55) | |||||
| ATC tool storage capacity (pcs) | 60 | |||||
| (Opt: 80, 100, 120, 160, 200, 240) | ||||||
| Machine weight (kg/working area mm) | 107000/4000 | 110000/4000 | 118000/5000 | 121000/5000 | ||
