Mô tả sản phẩm
- Machine structure to remove heat, vibration and misregistration
- Cooling Ball Screw
- Zero Gap Drive System
- Flat surface machining with a large number of tools
*SPECIFICATIONS:
| Item/Model | MVR30Fx | MVR35Fx | ||
| Table | Working area | Width (mm) | 2000 | 2500 |
| Length (mm) | 3000 Opt: 4000, 5000 | 4000 Opt: 5000 | ||
| Loading capacity (ton) | 20 | 25 Opt: 30 | ||
| Throat clearance between columns (mm) | 2550 | 3050 | ||
| Distance from spindle end to table surface (mm) | 1650 (Opt: 2000) | |||
| Ram | Ram size (mm) | 420x420 | ||
| Spindle speed (rpm) | 20,000 | |||
| Spindle motor output (cont/30 min) (kW) | 18.5/22 | |||
| ATC tool storage capacity (pcs) | 40 | |||
| (Opt: 60, 80, 100) | ||||
| Machine weight (kg/working area mm) | 55,400/3000 | 64,300/4000 | ||
